Descripción técnica
Cuadro
Cuadro:
Trackmachine 01 Premium Carbon with Aero Design | Steel Sliding Dropout | Compatible to fit BMC Pursuit Base Bar (sold separately)
Horquilla:
Trackmachine 01 | 01 Premium Carbon with Vmax Aero Design Hinge-Design
Seat
Tija de Sillín:
Trackmachine 01 | 01 Premium Carbon Aero Seatpost
Información adicional
Paso de rueda:
26mm measured tire
Peso:
3090g | Size M with steerer stem and all accessories
Clasificación ASTM:
Level 1
Límite de peso del sistema:
110kg
Reglamento relativo a la seguridad general de los productos (GPSR):
Instrucciones de seguridad GPSR (UE)
Persona responsable según el GPSR (UE)
Geometría
| Size | S | M | L |
|---|---|---|---|
| Rider Height | <173 | 170-185 | >183 |
| Reach | 434 | 459 | 452 |
| Stack | 436 | 471 | 526 |
| BB Drop | 64 | 64 | 64 |
| Fork Length | 364 | 364 | 364 |
| Fork Rake | 45 | 45 | 45 |
| Front Center | 605 | 642 | 653 |
| Head Tube | 41 | 78 | 135 |
| Head Tube Angle | 72° | 72° | 72° |
| Rear Center | 375-444 | 375-444 | 375-444 |
| Seat Angle | 75.5° | 75.5° | 75.5° |
| Seat Tube | 484 | 521 | 577 |
| Seatpost Length | 383 | 383 | 383 |
| Seatpost Offset | -18mm / 0mm / +18mm / +36mm | -18mm / 0mm / +18mm / +36mm | -18mm / 0mm / +18mm / +36mm |
| Standover Height | 747 | 782 | 837 |
| Top Tube | 554 | 588 | 596 |
| Trail | 62 | 62 | 62 |
| Wheelbase | 972-1042 | 1008-1078 | 1019-1089 |
