Tecnología
Descripción técnica
Cuadro
Cuadro:
Kaius 01 Premium Carbon with Aerocore Design | ICS Technology Stealth Cable Routing | Stealth Dropout Design | TCC Race Compliance Level | Flat Mount Disc | 12 x 142mm Thru-Axle
Horquilla:
Kaius 01 Premium Carbon | ICS Technology, Stealth Cable Routing | TCC Race Compliance Level | Stealth Dropout Design | Flat Mount Disc | 12 x 100mm Thru-Axle
Cockpit
Potencia:
BMC ICS2 | Integrated Cockpit System Technology
Manillar:
BMC RAB 03 | Ergo Top Shape | Compact Bend
Seat
Tija de Sillín:
Kaius 01 Premium Carbon D-Shaped Seatpost | 15mm Offset | D-Fender Compatible
Sillín:
Fizik Vento Argo R5 | 140mm
Transmisión
Platos y Bielas:
SRAM Rival DUB WIDE
Platos:
43-30T
Cassette:
SRAM Rival AXS XG-1250
Tamaño del cassette:
10-36T
Cadena:
SRAM Rival
Desviador Delantero:
SRAM Rival eTap AXS WIDE
Cambio Trasero:
SRAM Rival eTap AXS WIDE
Manetas de Cambio:
SRAM Rival eTap AXS HRD
Marchas:
2 x 12
Pedalier:
PF86 Bottom Bracket
Frenos
Pinzas de Freno:
SRAM Rival eTap AXS HRD
Discos:
SRAM Paceline | Centerlock
Tamaño del disco:
160 / 160mm
Ruedas
Llantas:
CRD-400 Carbon | Tubeless Ready | 40mm
Bujes:
CRD-400
Neumáticos:
Pirelli Cinturato Gravel H | 40mm
Información Tubeless:
Tubeless Ready Rims | Tubetype Tires
Información adicional
Paso de rueda:
44mm
Clasificación ASTM:
Level 2
Límite de peso del sistema:
120kg
Size | 47 | 51 | 54 | 56 | 58 | 61 |
---|---|---|---|---|---|---|
Rider Height | <166 | 166-174 | 172-180 | 178-186 | 184-192 | >190 |
Reach | 390 | 397 | 401 | 405 | 410 | 414 |
Stack | 510 | 530 | 550 | 570 | 595 | 620 |
Bar Drop | 125 | 125 | 125 | 125 | 125 | 125 |
Bar Reach | 70 | 70 | 70 | 70 | 70 | 70 |
Bar Width | 400 | 420 | 420 | 420 | 420 | 440 |
BB Drop | 80 | 80 | 80 | 80 | 80 | 80 |
Crank Length | 170 | 170 | 172.5 | 172.5 | 175 | 175 |
Fork Length | 387 | 387 | 387 | 387 | 387 | 387 |
Fork Rake | 50 | 50 | 45 | 45 | 45 | 45 |
Front Center | 596 | 610 | 608 | 619 | 632 | 644 |
Head Tube | 85 | 106 | 123 | 144 | 170 | 196 |
Head Tube Angle | 71 | 71 | 72 | 72 | 72 | 72 |
Rear Center | 420 | 420 | 420 | 420 | 420 | 420 |
Seat Angle | 73 | 73 | 73 | 73 | 73 | 73 |
Seat Tube | 428 | 452 | 468 | 493 | 513 | 533 |
Seatpost Length | 282 | 322 | 362 | 362 | 402 | 402 |
Seatpost Offset | 15 | 15 | 15 | 15 | 15 | 15 |
Standover Height | 684 | 722 | 756 | 780 | 798 | 818 |
Stem Angle | -12.5 | -12.5 | -12.5 | -12.5 | -12.5 | -12.5 |
Stem Length | 90 | 100 | 100 | 110 | 110 | 120 |
Top Tube | 546 | 559 | 569 | 579 | 592 | 604 |
Trail | 66 | 66 | 68 | 68 | 68 | 68 |
Wheelbase | 1003 | 1017 | 1015 | 1026 | 1039 | 1051 |
