Speedmachine 01 MOD | BMC | frames | Road, Road | Aero

Speedmachine 01 MOD

CARBON BLACK / NEON RED

Speedmachine 01 Premium Carbon Frame and Fork
Integrated Fueltank and Rear Storage
ICS Technology and Stealth Dropout Design

Regular priceUSD 6,999.00
USD /
Tax included.

SKU: 30005479
Size

Speedmachine 01 MOD

Parts & Accessories

  • Shipped to your local bike shop
Races don't occur in wind tunnels, but in the real world, where speed and adaptability matter. With the BMC Speedmachine 01 Frameset’s aerodynamics and positioning flexibility, we've optimized rider-centric design, merging feedback and innovative collaboration. It's not just about a bike's technical prowess, but ensuring the rider can harness that speed effectively.

Technology

Technical Overview

Frameset

Frame:
Speedmachine 01 Premium Carbon | ICS Technology Stealth Cable Routing | Integrated Fuel Tank 1200 Hydration System | Integrated Rear Storage 260 | Stealth Dropout Design | Flat Mount Disc | 142x12mm Thru-Axle

Fork:
Speedmachine 01 Premium Carbon | ICS Technology | Stealth Cable Routing | Stealth Dropout Design | Flat Mount Disc | 100 x 12mm Thru-Axle

Cockpit

Handlebar:
BMC Speedmachine Flat Cockpit | Profile Design Aeria Ultimate with Ergo+ Armrests and 45/25 SLC Aerobar Extensions

Seat

Seatpost:
BMC Speedmachine Seatpost 0 Offset | 0mm, 12.5mm, 25mm Offsets

Accessories

Fuel Tank 1200 with straw and bite valve, Rear Storage 260, Intergrated Rear Light | SHIMANO Seatpost battery holder sold separately

Additional Information

Tire Clearance:
30mm

Weight without Pedals:
3.9 Kg (including FuelTank, Rear Storage and Light)

ASTM Classification:
Level 1

System Weight Limit:
110kg

Size S M L
Rider Height <174 172-185 >180
Bar Width 400 400 400
BB Drop 62 72 72
Crank Length 165 170 172.5
Fork Length 391 391 391
Front Center 578 606 646
Pad Reach Flat Cockpit 348-466 368-486 395-548
Pad Stack Flat Cockpit 558-651 588-681 628-721
Rear Center 405 405 405
Saddle Height Range 610-740 705-835 760-881
Seat Angle 80 80 82.4
Seat Tube 460 525 551
Seatpost Length 300 330 360
Seatpost Offset 0, 12.5, 25 0, 12.5, 25 0, 12.5, 25
Standover Height 766 806 837
Wheelbase 974 1000 1040
