Timemachine 01 DISC ONE

STEALTH

SRAM Force eTap AXS Drivetrain
DT Swiss ARC 1650 Carbon Wheelset
P2P Flat Cockpit, BMC Aero Post

Regular priceUSD 9,499.00
USD /
Tax included.

SKU: 30002545
Size

Timemachine 01 DISC ONE

Parts & Accessories

  • Shipped to your local bike shop
The Timemachine 01 DISC is the latest evolution of our all-conquering, drag-defying race machine. Its highly sophisticated aerodynamics, adjustability and component integration ensure you can perform at your best. The Vmax Aero Design Premium Carbon frame includes aero disc caliper covers, sliding dropouts, rear storage, a dual position seatpost and our Flat Cockpit with Profile Design T4+ Carbon extensions. Its SRAM Force eTap AXS 12-speed groupset and 62mm DT Swiss ARC 1650 Carbon wheelset are geared for speed on this time trial and triathlon bike.

Technology

Technical Overview

Frameset

Frame:
Timemachine 01 Disc Premium Carbon with Vmax Aero Design and P2P Positioning SyStem | Internal Di2 Battery Mount | PF86 Bottom Bracket | Rear Storage | BoxAero Caliper Cover | Sliding Dropouts | Flat Mount Disc | 12 x 142mm Thru-Axle

Fork:
Timemachine 01 Disc Premium Carbon with Vmax Aero Design Hinge Design | Aero Caliper Cover | Flat Mount Disc | 12 x 100mm Thru-Axle

Cockpit

Handlebar:
BMC Flat Cockpit | Profile T4+ Carbon Extensions

Seat

Seatpost:
Timemachine 01 Premium Carbon V-Max Aero Seatpost

Saddle:
Fizik Mistica Mg

Brakes

Brake Levers / Calipers:
SRAM S-900 Aero HRD Disc Brake

Rotors:
SRAM Centerline X

Rotor Size (F/R):
160 / 160mm

Wheels

Rims:
DT Swiss ARC 1650 Carbon Disc | 62mm

Hubs (F/R):
DT Swiss ARC 1650 Disc

Tires:
Pirelli P Zero Race | 26mm

Accessories

Aerocore Bottle Cages

Additional Information

Tire Clearance:
27mm

ASTM Classification:
Level 1

System Weight Limit:
110kg

Size S S-M M-L L
Rider Height <170 172-180 178-188 186-196
Reach 393 377 418 442
Stack 480 515 515 556
Base Bar Drop Flat Cockpit +/- 80 +/- 80 +/- 80 +/- 80
Base Bar Drop V-Cockpit 85 85 85 85
Base Bar Reach Flat Cockpit 619 612 653 670
Base Bar Reach V-Cockpit 617 611 652 669
BB Drop 58 68 68 68
Crank Length 165 170 170 172.5
Fork Length 374 374 374 374
Fork Rake 45 45 45 45
Front Center 580 578 619 649
Head Tube Angle 71.5 71.5 71.5 71.5
Pad Reach Flat Cockpit 388 - 474 381 - 467 422 - 508 438 - 524
Pad Reach V-Cockpit 366 - 530 359 - 522 400 - 563 417 - 580
Pad Stack Flat Cockpit 535 - 610 555 - 630 555 - 630 595 - 670
Pad Stack V-Cockpit 593 - 643 616 - 665 616 - 665 656 - 705
Rear Center 400 400 400 400
Saddle Height Range 630 - 780 660 - 850 660 - 850 700 - 880
Seat Angle 71.5 - 80.8 71.5 - 80.8 71.5 - 80.8 71.5 - 80.8
Seat Tube 495 550 550 592
Seatpost Offset 27 / 9 / -9 / -27 27 / 9 / -9 / -27 27 / 9 / -9 / -27 27 / 9 / -9 / -27
Standover Height 755 797 797 838
Stem Angle p2p p2p p2p p2p
Stem Length p2p p2p p2p p2p
Trail 60 60 60 60
Wheelbase 972 968 1009 1039
