Cuadro:
URS AMP Premium Carbon with Micro Travel Technology | Gravel+ Geometry | Integrated Battery | Internal Cable Routing | Fender and Rack Mounts | Flat Mount Disc | 12 x 142mm Thru-Axle | UDH Dropout Universal Derailleur Hanger
Horquilla:
Micro Travel Technology Suspension Fork Premium Carbon blades | 20mm Travel | Coil Spring & Hydraulic Damper | Fender Mounts | Flat Mount Disc | 12 x 100mm Thru-Axle
Suspensión Delantera:
Micro Travel Technology Suspension Fork | Premium Carbon Blades | 20mm Travel | Coil Spring & Hydraulic Damper | Cargo Mounts | Fender Mounts | Hub-Dynamo Cable Routing
Suspensión Trasera:
Micro Travel Technology Stays
Motor:
TQ-HPR60 Drive Unit
Batería:
TQ Battery | 360 Wh | Certified by UL LLC
Display:
TQ Grafic color Display | 2" O-LED | Bluetooth / ANT+
Cargador:
TQ 4A Charger
Potencia:
BMC MSM
Manillar:
BMC HB D4 03, 0, 16 | Alloy 6061 | 115mm drop, 70mm reach, 16° flare
Tija de Sillín:
URS AMP Premium Carbon D-Shaped Seatpost | 0mm Offset | D-Fender Compatible
Sillín:
WTB Gravelier Stainless | Medium
Platos y Bielas:
Praxis eCrank Alloy Road
Platos:
38T
Cassette:
SHIMANO SLX CS-M7100
Tamaño del cassette:
10-51T
Cadena:
SHIMANO CN-M7100
Cambio Trasero:
SHIMANO Deore XT Di2 (RD-M8260) | Wired for E-Bike
Manetas de Cambio:
SHIMANO GRX Di2 (ST-RX825)
Marchas:
1 x 12
Pinzas de Freno:
SHIMANO GRX (BR-RX820)
Discos:
SHIMANO RT-CL800
Tamaño del disco:
180 / 180mm
Llantas:
AG 20 | Tubeless Ready | 20 mm
Bujes:
AG 20
Neumáticos:
WTB Raddler | 44mm
Información Tubeless:
Tubeless Rim | Tubeless Tires
En la caja:
X-Cages │Cargo Strap
Paso de rueda:
47mm
Clasificación ASTM:
Level 2
Límite de peso del sistema:
120kg
Reglamento relativo a la seguridad general de los productos (GPSR):
Instrucciones de seguridad GPSR (UE)
Persona responsable según el GPSR (UE)
| Size | XS | S | M | L | XL |
|---|---|---|---|---|---|
| Rider Height | <167 | 165-170 | 168-178 | 176-188 | >188 |
| Reach | 390 | 400 | 410 | 420 | 430 |
| Stack | 570 | 570 | 580 | 610 | 640 |
| Bar Drop | 115 | 115 | 115 | 115 | 115 |
| Bar Reach | 70 | 70 | 70 | 70 | 70 |
| Bar Width | 390/459 | 410/479 | 410/479 | 430/499 | 430/499 |
| BB Drop | 72 | 72 | 72 | 72 | 72 |
| Crank Length | 170 | 170 | 170 | 170 | 170 |
| Fork Length | 427 | 427 | 427 | 427 | 427 |
| Fork Rake | 45 | 45 | 45 | 45 | 45 |
| Front Center | 635 | 644 | 652 | 673 | 694 |
| Head Tube | 130 | 130 | 133 | 165 | 197 |
| Head Tube Angle | 69 | 69 | 69.5 | 69.5 | 69.5 |
| Rear Center | 435 | 435 | 435 | 435 | 435 |
| Seat Angle | 75 | 75 | 75 | 75 | 75 |
| Seat Tube | 425 | 439 | 475 | 505 | 540 |
| Seatpost Length | 310 | 360 | 360 | 360 | 360 |
| Seatpost Offset | 0 | 0 | 0 | 0 | 0 |
| Standover Height | 729 | 746 | 761 | 781 | 800 |
| Stem Angle | ±7 | ±7 | ±7 | ±7 | ±7 |
| Stem Length | 70 | 70 | 70 | 80 | 90 |
| Top Tube | 540 | 551 | 563 | 582 | 601 |
| Trail | 90 | 90 | 86 | 86 | 86 |
| Wheelbase | 1061 | 1070 | 1077 | 1098 | 1119 |
